| MOQ: | 1 set |
| Price: | Negotiable |
| Standard Packaging: | The glass parts will be wrapped with foam, then put into the carton; the mainbody portion will be packde in wooden case. |
| Delivery Period: | within 5days after payemnt received |
| Payment Method: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Capacity: | 500 sets/momth |
100L Stainless Steel Chemical Reactor Borosilicate Glass Reactor Eco Friendly Customized
The Stainless Steel Chemical Reactor heats or refrigerates the materials in the reactor at constant temperature, and can provide chemical reactions such as stirring polymerization. The material reacts in the reactor and can control the evaporation and reflux of the reaction solution. After the reaction, the material can be released from the outlet at the bottom of the kettle, and the operation is very convenient. It is an ideal equipment for the synthesis of modern chemical samples, medium sample experiments, biopharmaceuticals and new materials.
|
Product Model |
PGR-3 |
PGR-5 |
PGR-10 |
PGR-30 |
PGR-50 |
PGR-100 |
PGR-200 |
|
Volume(L) |
3 |
5 |
10 |
30 |
50 |
100 |
200 |
|
Neck No.on Cover |
4 |
5 |
6 |
6 |
6 |
6 |
6 |
|
External Diameter of Inner Vessel(mm) |
150 |
180 |
230 |
330 |
365 |
460 |
600 |
|
External Diameter of Outer Vessel(mm) |
200 |
230 |
290 |
365 |
410 |
500 |
650 |
|
Cover Diameter(mm) |
150 |
180 |
265 |
265 |
265 |
340 |
340 |
|
Vessel Height(mm) |
300 |
400 |
450 |
730 |
850 |
950 |
1200 |
|
Motor Power(W) |
40 |
60 |
140 |
140 |
140 |
250 |
750 |
|
Vacuum Degree(Mpa) |
0.098 |
0.098 |
0.098 |
0.098 |
0.098 |
0.098 |
0.098 |
|
Rotation Speed(rpm) |
50-1400 |
50-600 |
50-600 |
50-600 |
50-600 |
50-600 |
50-600 |
|
Torque(Nm) |
0.27 |
0.95 |
2.23 |
2.23 |
2.23 |
3.98 |
6.37 |
|
Power(V) |
220 |
220 |
220 |
220 |
220 |
220 |
220 |
|
Dimension(mm) |
320*350*900 |
450*450*1200 |
650*650*1900 |
700*500*2100 |
800*600*2300 |
1000*700*2700 |
1200*900*3200 |
Main Features
※ Seal Assembly
You need to seal the reactor vessel well so that you can regulate the pressure. In most cases, the 50L glass reactor will come with a seal assembly which plays a great role in ensuring the system has the perfect seal in place.
※ Discharge Value
After the reaction is over, you need to discharge the ingredients. The unit comes with a discharge valve which makes it possible to discharge the ingredients. You can count on the unit to achieve the best product discharge. There is a minimal mess due to the high-quality construction of the discharge unit.
※ Heating And Cooling System
There should be a way of heating and cooling the ingredients during the chemical reaction. The reactor has a unit that allows for effective cooling and heating of the ingredients.
※ Customizable
Packing And Delivery
※ 1 year complimentary warranty
※ Training how to install the machine and how to operatate
※ Free lifetime maintenance service and 24-hour technical support
※ Engineers available to service machinery overseas
※ Reliable quality and thoughtful after sale service
Our Factory
Nantong Sanjing Chemglass Company summarize:Established in 2006, Nantong Sanjing Chemglass Co., Ltd. is a manufacturer and trader specialized in research, development and production of chemical glass instrument. Main products include glass reactor, wiped film evaporator, rotary evaporator, short-path molecular distillation device and chemical glass tube.
Advantage of us is customize according to client need. We can provide relevant industry with design, manufacturing, equipment selection, instrument supporting, installation, debugging, maintenance.
Our Service
Customizable
Provide free technical advice.
The seller can provide detailed equipment parameters and configuration list.
The warranty period of the company's products is 12 months from the date of acceptance of the equipment (excluding glass fitings andconsumables).
If there are quality problems in the parts during the warranty period,the seller can provide free replacement of malfunction components;if the damage is due to human factors, when the parts need to bereplaced, the seller will provide the accessories and charge themaintenance cost.
